J275 F
J275 F - Image 2

J275 F

Our strength is the wide range: whatever the need, ranging from residential security installation to the highest level of anti-terrorism securities, we have it all.
We offer wide range of bollards that goes beyond just the function of protection, it enhances the appeal of the architecture and the streetscape. Our bollards models are available in different materials, designs , protection level meant for protecting diverse type of premises. We can offer customized solutions matching the properties architecture & landscape. Our products and accessories always provide for the possibility to find the ideal solution to satisfy any needs regarding management, safety, and design.

Category:

Description

The Fixed traffic bollard FAAC J275 does not require invasive installation work, nor electrical wiring. It is therefore ideal for permanent installations to define pedestrian areas, or for mixed installations which also feature other retractable bollards.

  1. Power supply and wiring not required
  2. Simple installation and limited digging operations
  3. Observance of aesthetic consistency in mixed installations with other retractable bollards
  4. Possibility to remove the bollard to temporarily open the pedestrian area to traffic

Technical Specifications

J Series Model  J275 F H600  J275 F H600 INOX  J275 F H800  J275 F H800 INOX
Cylinder height from ground [mm]  600  600  800  800
Cylinder diameter [mm]  275  275  275  275
Cylinder material  Steel SJ235JR EN 10219 (4mm thick)  AISI 316L satin finish. (3mm thick)  Steel SJ235JR EN 10219 (4mm thick)  AISI 316L satin finish. (3mm thick)
Cylinder surface  Cataphoresis and polyester powder painted

Dark grey metall. RAL 7021

 Satin finishing  Cataphoresis and polyester powder painted

Dark grey metall. RAL 7021

 Satin finishing
Head  Aluminium RAL 9006  Aluminium RAL 9006  Aluminium RAL 9006  Aluminium RAL 9006
Reflective strip height [mm]  55  55  55  55
Reflective strip colour  Orange  Orange  Orange  Orange
Break in resistance [J]  35.000  59.000  35.000  59.000
Total weight [Kg]  34  34  38  38
Underground product dimensions WxDxH  [mm]  450 x 450 x 55  450 x 450 x 55  450 x 450 x 55  450 x 450 x 55
Required excavation dimensions WxDxH  [mm]  750 x 750 x 150  750 x 750 x 150  750 x 750 x 150  750 x 750 x 150
